Metal Fire Rated Door
Metal fire rated doors are specially engineered steel doors designed to prevent the spread of fire and smoke for a specified period. Manufactured using high-quality galvanized steel and fire-resistant core materials, these doors provide maximum safety, durability, and structural strength. They are ideal for commercial buildings, factories, hospitals, hotels, and residential projects where fire protection is essential.
Door Type:Metal Fire Rated Door
Fire Rating:120 mins
Shutter Thickness:46 mm
Criteria:Stability, Integrity & With Insulation
Material
Testing Standards:BS 476 Part 20-22, IS 3614 Part 2
Frame Size
:100 x 57mm Single Rebate
143 x 57mm Double Rebate.
Construction Details
* Steel Frame Profile Design
* Frame Thickness - 1.20 mm/ 1.60 mm Galvanized Steel
* Shutter Sheet Thickness - 1.0 / 1.2 mm Galvanized Steel
* Vision Panel - 2hrs. Fire rated Toughened clear Glass
( Optional)
* Shutter Thickness - 46 mm
* Shutter Infill Insulation - Fire Rated Insulation
* Finish powder coated finish in desired shade
Recommended Hardware
1. SS Ball Bearing Hinges - SS 304 of
Size 100mm x 75mm x 3mm
2. Door Closer - Fire rated
3. Tower Bolt / Flush Bolt
Optional Hardware
4. Mortise Dead Lock Set with Cylinder- complete with
D Shape Pull handle for Push / Pull Operations
5. Mortise Sash Lock with Cylinder -
Complete with Lever Handle for Push / Pull Operations
6. Fire Rated Panic Bar - Push Side Operation
Fire Rated External Panic Trim - Pull Side Operation
Recommended Finishes
1 Powder Coating in desired RAL Shade Code
2 Polyurethane Coating in desired RAL Shade Code
3 Selective Wood Grain Finishes available
